HIGH SPEED. HIGH PRECISION, HIGH LOAD CAPACITY. HIGH RIGIDITY. HIGH EFFICIENCY

• HMC-50 horizontal machining center is a horizontal machining center with cross slide structure, which has the advantages of smaller footprint and faster speed compared to the same size horizontal machining center with ‘T' structure.

• It is suitable for various machinery making industries such as aviation, automobile, mold, shipbuilding, electromechanics, machine tool, printing, light textile, etc. It is mainly used for a variety of processing such as small and medium-sized parts and molds.

• Heavy duty high precision roller guide can withstand large load cuing. High-grade Meehaner castings reduce twisting deformationand have good vibration damping.The spindle adopts high power wide constant torque motor with high cutting efficiency.The table adopts imported gear plate positioning, positioning accuracy ±5", repeat positioning accuracy ±3"

HIGH SPEED, HIGH PRECISION, HIGH LOAD CAPACITY, HIGH RIGIDITY, HIGH EFFICIENCY

• TH series horizontal machining center is metal cutting equipment with high rigidity, high speed, high precision and high reliability.

• Widely applied in automotive, aerospace, electronics industry, various types of cases. shell-type parts processing.

• The base adopts the "T" layout, optimized by the finite element analysis, the casting tendon arrangement structure. improve the overall performance index, the full stroke does not produce overturning momentAdopt high precision spindle, standard speed 6000rpm, with spindle air curtain protection, stable precision and long life.

• The spindle adopts high power constant torque motor.

• High rigidity roller guide structure, both the heavy cutting rigidity of hard rail and the fast moving characteristics of linear guide.

• The double support pre-stretching of the screw eliminates the backlash of the transmission and compensates the error caused by the temperature rise in advance.

• Precision rotary table with ultra-high positioning and repeat positioning accuracy to ensure workpiece machining accuracy

TL4211  TL4216 LATHE
